以下为部分产品技术参数，更多资讯请或电邮winnsky@winnsky.com
|
型號 Part Number |
类型 Model |
中心頻率 Fo（MHz) |
插損 I.L(dB) |
帶 宽 BW(MHz) |
波 動 Ripple(dB) |
駐波比 V.S.W.R |
外形尺寸 Size（mm) |
| LF43L0500H72-L32 | 500 | ≤3.5 | 100～900 | ≤1.2 | ≤2.0 | 4.5*3.2*2.0 | |
| LF43L0865H82-L24 | 865 | ≤3.8 | 5～865 | ≤1.2 | ≤2.0 | 4.5*3.2*2.0 | |
| LF43L1190H72-L42 | 1190 | ≤3.0 | 950～1430 | ≤2.0 | 4.5*3.2*2.0 | ||
| LF43L1200P57-L01 | 1200 | ≤2.3 | 950～1450 | ≤1.5 | ≤2.2 | 4.5 *3.2 *2.2 | |
| LF43B1200H2111-N51 | 1200 | ≤2.5 | ±250 | ≤1.0 | ≤1.8 | 4.5*3.2*1.5 | |
| LF23B1420P56-N81 | 1420 | ≤2.5 | ±30 | ≤1.0 | ≤2.0 | 2.5*3.2*1.2 | |
| LF34B1460P46-N85 | 1460 | ≤4.0 | 1335～1585 | ≤0.75 | ≤2.0 | 3.2*4.5*1.5 | |
| LF32B1890P47-N01 | 带通/B.P.F | 1890 | ≤2.2 | ±10 | ≤1.0 | ≤2.0 | 3.2*2.5*1.5 |
| LF23B1890P56-N30 | 1890 | ≤1.8 | ±10 | ≤0.5 | ≤2.0 | 2.5*3.2*1.5 | |
| LF32B1907P47-N01 | 1906.5 | ≤1.25 | ±13.5 | ≤1.0 | ≤2.0 | 3.2*2.5*1.5 | |
| LF23B1907P56-N30/2 | 1907.5 | ≤1.8 | ±13.5 | ≤0.5 | ≤2.0 | 2.5*3.2*1.5 | |
| LF32B1910P47-N01 | 1910 | ≤2.2 | ±10 | ≤1.0 | ≤2.0 | 3.2*2.5*1.5 | |
| LF23B1919P56-N30/L | 1919 | ≤1.2 | ±11 | ≤0.5 | ≤2.0 | 2.5*3.2*1.5 | |
| LF21B2450H72-N176 | 2450 | ≤1.5 | 2400～2500 | ≤2.0 | 2.0 *1.25*0.95 | ||
| LF21B2450H61-N175 | 2450 | ≤1.5 | 2400～2500 | ≤2.0 | 2.0 *1.25*0.95 | ||
| LF18B2450P57-N174 | 2450 | ≤1.7 | 2400～2500 | ≤2.0 | 1.6*0.8 *0.6 | ||
| LF21L2450H57-L02 | 2450 | ≤1.2 | 2400～2500 | ≤0.5 | ≤1.8 | 2.0 *1.25*0.9 | |
| LF22B2450P57-N06 | 2450 | ≤3.0 | 100 | ≤1.0 | ≤2.0 | 2.5 *2.0 *1.0 | |
| LF12B2450P58-N16 | 2450 | ≤1.8 | 101 | ≤0.8 | ≤2.0 | 1.25*2.0 *1.0 | |
| LF22B2450P47-N21 | 2450 | ≤1.8 | 102 | ≤0.8 | ≤2.0 | 2.5 *2.0 *1.2 | |
| LF31B2450P56-N22 | 2450 | ≤2.6 | 103 | ≤0.8 | ≤2.0 | 3.2 *1.6*1.2 | |
| LF22B2450P47-N24 | 2450 | ≤2.0 | ±50 | ≤1.0 | ≤2.0 | 2.5 *2.0 *1.2 | |
| LF21B2450H46-N36 | 2450 | ≤1.7 | ±50 | ≤0.8 | ≤2.0 | 2.0 *1.25*0.95 | |
| LF21B2450H92-N39/E | 2450 | ≤1.9 | ±50 | ≤1.0 | ≤2.0 | 2.0 *1.25*0.95 | |
| LF22B2450P57-N41 | 2450 | ≤2.0 | 200 | ≤1.0 | ≤2.0 | 2.5*2.0*1.0 | |
| LF21B2450H56-N76 | 2450 | ≤3.2 | 100 | ≤1.0 | ≤2.0 | 2.0 *1.25*0.95 | |
| LF18B2450P44-N78 | 2450 | ≤2.2 | 100 | ≤1.0 | ≤2.0 | 1.6*0.8 *0.6 | |
| LF21B2450H86-N170 | 2450 | ≤2.4 | 100 | ≤2.0 | 2.0*1.25*0.95 | ||
| LF22B3500P56-N64 | 3500 | ≤2.8 | 210 | ≤0.5 | ≤2.0 | 2.5 *2.0 *1.0 | |
| LF43B3500P34-N42 | 3500 | ≤3.0 | 0 | ≤1.0 | ≤2.0 | 4.5 *3.2 *1.5 | |
| LF18H5375H54-H46 | 5375 | ≤0.6 | ±475 | ≤1.8 | 1.6*0.8*0.6 | ||
| LF21B5390P67-N26 | 5390 | ≤2.5 | 0 | ≤1.0 | ≤2.0 | 2.0 *1.25*0.95 | |
| LF18B5425H1411-N172 | 5425 | ≤0.85 | 0 | ≤2.1 | 1.6*0.8*0.6 | ||
| LF21L5512P44-L06 | 5512 | ≤1.6 | 0 | ≤0.5 | ≤2.0 | 2.0 *1.25*0.95 | |
| LF21B5700H75-N169 | 5700 | ≤2.7 | ±450 | ≤1.55 | 2.0*1.25*0.95 | ||
| LF21B5787P67-N17 | 5787.5 | ≤2.5 | ±62.5 | ≤1.2 | ≤2.0 | 2.0 *1.25*0.95 | |
| LF22B5800P45-N58 | 5787.5 | ≤2.6 | ±62.5 | ≤1.0 | ≤2.0 | 2.5 *2.0 *1.0 | |
| LF31B5800P36-N20 | 5800 | ≤2.3 | ±50 | ≤1.0 | ≤2.0 | 3.2 *1.6*1.2 |
以上为部分产品技术参数，更多资讯请或电邮winnsky@winnsky.com
